Product overview
FST100-321 is a terminal device for remote data collection and control. It mainly has functions such as data collection, data transmission, and remote control. It can be widely used in industrial automation, energy management, environment, geology, and hydrological monitoring. It provides multiple versions to choose from, including NB-IoT, CAT-M, 4G-CAT1, and LoraWAN. It uses disposable lithium-ion batteries as the default power supply. It also supports DC external power supply rechargeable batteries and built-in/external antenna versions to meet the application requirements of different scenarios.
Features
◇ Low power consumption design.
◇ Protection level IP68.
◇ Support external 5V/9V/12V DC power supply.
◇ Integrated analog input, serial port and other types of communication interfaces.
◇ Data can be wirelessly transmitted to the cloud platform.
◇ Built-in watchdog improves product stability.
◇ It has wireless remote firmware upgrade function, which is convenient for firmware upgrade and remote maintenance.
Technical indicators
Network standard | NB-IoT、CAT-M |
4G-CAT1 | |
LoraWAN (470~510MHz) (Multiple frequency bands available: RU864/IN865/EU868/US915/AU915/KR920/AS923-1&2&3&4) | |
Power supply | DC3.6V 19000mAh (outdoor black shell - built-in 1 ER34615), supports external DC power supply |
DC3.6V 38000mAh (outdoor large black shell - built-in 2 ER34615) | |
Working environment | Ambient temperature -30℃~+70℃ Relative humidity ≤95% Waterproof grade IP68 Anti-electromagnetic interference Complies with GB/T 17626 standard |
IoT platform | Azure、AEP |
Communication protocol (working mode) | UDP (CoAP)/TCP/MQTT (SSL/TLS encryption is supported under MQTT) |
Standard LoRaWAN® protocol OTAA/ABP Class A (default) and Class C Class A | |
Hardware/communication interface | Built-in interfaces: ►1 flip-up SIM card holder ►1 magnetic interface for waking up the device ►2 LED indicators LED operation mode 2s on 2s off; sampling 1s on 1s off; data transmission 500ms on 500ms off; sleep mode off; External interfaces: ►2 waterproof aviation plug interfaces Interface 1-Sensor interface (VCC/GND/AI1/AI2/A/B) Analog signal 4-20mA, 0-5V, 0-10V interface, RS485 sensor, I2C interface Expansion interface 2-DI/DO/external power supply access/TTL interface/debugging interface ►Support internal/external antenna |
Magnetic suction/button operation | Sleep mode status: enter operation mode from power saving mode Press and hold for 8~15s to restart the device |
Keywords:Industry Sensor Manufacturers,IOT sensor Suppliers,Firstrate Sensor
FST100-321 Low Power Consumption Intelligent Data Acquisition Terminal
Features:
◇ Low power consumption design.
◇ Protection level IP68.
◇ Support external 5V/9V/12V DC power supply.
◇ Integrated analog input, serial port and other types of communication interfaces.
◇ Data can be wirelessly transmitted to the cloud platform.
◇ Built-in watchdog improves product stability.
◇ It has wireless remote firmware upgrade function, which is convenient for firmware upgrade and remote maintenance.
