Product model: FST100-6101
Product Features:
♦ Low power consumption design,powered by lithium battery
♦ Eliminate wiring construction,easy installation and maintenance
♦ GPRS wireless transmission
Product Center
All categories
All categories
All categories
1/1
Number of views:
1000
FST100-6101LoRa Wireless Temperature Sensor
Retail price
0.0
元
Market price
0.0
元
Number of views:
1000
Product serial number
FST100-6101
Quantity
-
+
Stock:
0
Introduction
【Product Description】
FST100-6101 wireless temperature sensor uses high-quality sensitive temperature measurement devices, and is also equipped with ultra-low power microprocessor and high-precision sensor signal conditioning circuit as a whole. It adopts 4G/4G-CAT1/LoRa/NB-IoT communication network to realize on-site Wireless transmission of monitoring data to the cloud. Customers can obtain measurement data by logging in to the relevant website through the Internet PC or mobile terminal, and realize the statistics and analysis of the collected data, and form reports and data curves, which are intuitive, accurate and efficient. This product is mainly used in water supply pipe network, gas supply pipe network, oil supply pipe network, environment, medical and health, manufacturing, chemical industry, energy, meteorology, storage, cold storage, freezer and high-voltage power transmission temperature monitoring and other fields.
【Technical Parameters】
| Measuring range | -50~400℃, LCD display (optional), measuring range> 120℃, using isolated type | |
| Transfer method | 4G/4G-CAT1/LoRa/NB-IoT，LoRa Working frequency band: 470MHz/868MHz | |
| Protocol | MQTT protocol：4G/NB-IoT;LWM2M protocol：NB-IoT；LoRaWAN protocol： LoRa (Class A, OTAA mode activation) |
|
| Power supply | 3.6V battery power supply or 12~30VDC external power supply | |
| Power consumption current | 4G/NB-IoT Sleep current：≤20uA Sampling current：≤5mA（Lasts 1s） Communication average current：≤60mA（Lasts 15s） Online current：≤10mA（Lasts 60s） |
LoRaWAN Sleep current is less than 20uA Sampling current is less than 5mA Sending current is less than 140mA Receiving current is less than 20mA |
| Upload frequency | 5-1440 minutes can be set | |
| Precision | ±0.5%FS、1%FS | |
| Battery capacity | 8000mAh | |
| Withstand voltage | Typical：40bar（Max：300bar） | |
| Ambient temperature | -20~60℃，0%~80%RH | |
| Protection level | IP65 | |
| Material | 304, aluminum die casting | |
| Installation interface | M20*1.5 G1/4 (others need to be customized) | |
| Sampling frequency | 10-3600s can be set, 10s~12h can be set (default 10s) | |
| Transmission distance | Depending on signal strength LoRaWAN Open environment：2000Meter City environment：1000Meter |
|
【Product appearance and electrical connection】
【Scope of application】
♦ Industrial process detection and control
♦ Cooling and heating system
♦ Automatic system temperature measurement and control
♦ Unattended and dangerous areas
【Company Profile】
【Packaging & Shipping】
