【Product Features】
● Sturdy and reliable, oil-resistant and corrosion-resistant
● Linear measurement, absolute value output
● LED indicator diagnostic function
● High precision, high resolution
● Modular universal design, easy maintenance
● Non-contact measurement, no wear
● Low power consumption, low temperature drift
【Application Range】
● Hydraulic control system, metallurgical equipment, wind power generation
● Engineering machinery, rubber machinery
● Port machinery, injection molding machine
● Flight simulator
● Hydroelectric power station, solar power station, real-time monitoring of reflection angle
【Technical Parameters】
| Testing Data | Position |
| Testing Range ( mm ) | 300mm 400mm 500mm 600mm 700mm 800mm 900mm 1000mm |
| Output Signal | 4~20mA |
| Supply voltage | 24VDC (-15% ~ + 20%) |
| Working current | <70mA |
| Polarity protection | Maximum -30VDC |
| Maximum pressure protection | 33VDC |
| Resolution | 16-bit D / A |
| Non linearity | ± 0.1% FS ± 0.3% FS |
| Repeatability | ± 0.008% FS |
| Update time | Analog signal 0.5mS (travel <1000mm) |
| Operating temperature | -40 ~ +85 ℃ |
| Storage temperature | -40 ~ +100 ℃ |
| Temperature effect | <0.007% FS / ℃ |
| Dew point | Humidity 90%RH, no condensation |
| Error indication | LED indicator diagnosis function |
| Position magnetic ring | Toroidal magnetic ring |
| Rod pressure | ≤ 34MPa |
| Installation form | M18x1.5 thread |
| Electrical Interface | Straight out cable |
| IP Grade | IP67 |
【Detailed description】
Keywords:Industry Sensor Manufacturers,IOT sensor Suppliers,Firstrate Sensor
FST400-1100 Waterproof Magnetostrictive Displacement Sensor
Product model: FST400-1100
Product features :
● Excellent reliable, oil and corrosion resistant ● LED indicator diagnosis function
● Low power consumption, low temperature drift ● High precision, high resolution
● Modular universal design, easy maintenance ● Non-contact measurement, no wear
